A POS station can look complete while one missing cable keeps the cash drawer closed, the receipt printer offline, or the payment terminal unable to process transactions. Understanding what cables connect POS equipment helps restaurant operators, installers, and IT teams order the right components before installation day and replace failed connections without interrupting service.
The required cable depends on the device, its port type, the POS software or terminal model, and whether the equipment communicates directly with a workstation or across the restaurant network. USB and Ethernet cover many modern installations, but serial, cash drawer, video, and specialized power connections still matter in active restaurant environments.
What Cables Connect POS Equipment at the Counter?
A typical front-counter POS setup may include a touchscreen terminal, customer-facing display, receipt printer, barcode scanner, cash drawer, payment terminal, and network connection. These devices do not all use the same cable. Confirm the ports on both ends before ordering, especially when replacing older equipment.
USB cables for peripherals
USB is the most common direct-connect interface for current POS hardware. A USB Type-A connection is common on POS terminals and PCs, while peripherals may use USB Type-B, Mini-B, Micro-B, USB-C, or a permanently attached USB lead.
USB cables commonly connect barcode scanners, receipt printers, label printers, customer displays, keyboards, scales, and certain cash drawers. USB is practical because it carries data and, for many small peripherals, limited power through one cable. Cable length still matters. A long USB run can cause intermittent detection or power problems, particularly with bus-powered devices. For a fixed counter setup, use an appropriately sized, commercial-grade cable rather than joining multiple extension cables.
Some printers support both USB and Ethernet. USB works well when the printer stays beside one POS terminal. Ethernet is generally the better choice when multiple stations need access to the printer or when the printer is located away from the register.
Ethernet cables for networked POS devices
Ethernet cables connect devices to a router, switch, firewall, or wall network jack. Most restaurant POS networks use Cat5e or Cat6 cable with RJ45 connectors. Cat6 is a common choice for new installs because it supports current network requirements and provides useful headroom for future equipment.
Ethernet is used for POS workstations, cloud POS terminals, receipt and kitchen printers, IP payment terminals, kiosks, access points, IP cameras, network video recorders, and managed switches. Unlike a direct USB connection, Ethernet allows devices to communicate across the local network. That makes it especially useful for kitchen printers, drive-thru stations, back-office systems, and multi-lane counter installations.
Use patch cables for short connections from equipment to a switch or wall jack. For permanent in-wall runs, use bulk-rated structured cable, proper terminations, and labeling. Avoid running network cable beside high-voltage electrical lines when possible, since electrical interference and poor routing can create difficult-to-trace connection issues.
Power cords and DC power supplies
Every POS device needs a compatible power connection, whether it uses a standard AC power cord, an external power brick, USB-C power delivery, or a dedicated DC adapter. Power cables are often treated as interchangeable when they are not.
For equipment using a DC adapter, match the output voltage, polarity, connector size, and required amperage. An adapter with the wrong voltage can damage equipment. An adapter with insufficient amperage may allow a device to start but fail during printing, scanning, or peak usage. Keep spare approved power supplies for high-priority devices such as receipt printers, network switches, payment equipment, and POS terminals.
Cables Used for Printers and Cash Drawers
Receipt printers and cash drawers are closely related, but their connections are often misunderstood during replacement projects.
Printer data cables
Thermal receipt printers may connect through USB, Ethernet, serial, parallel, Bluetooth, or Wi-Fi, depending on the model. For restaurant installations, wired USB or Ethernet is normally preferred for fixed printers because it avoids battery management and wireless signal variables.
Serial printers remain in use at older sites. They use an RS-232 connection, often with a DB9 connector, and may require a straight-through or null-modem cable depending on the equipment. Serial communication settings must also match: baud rate, parity, data bits, stop bits, and flow control. A physically correct cable will not resolve a configuration mismatch.
Kitchen printers are often best connected by Ethernet when the kitchen is separated from the front counter. This supports central network management and avoids long USB cable runs through service areas.
Cash drawer cables
Most POS cash drawers do not connect directly to the computer. Instead, the drawer plugs into the receipt printer's cash drawer port using an RJ11 or RJ12-style cable. When the POS sends an open-drawer command to the printer, the printer sends a pulse to the drawer.
These connectors may resemble a telephone cable, but they are not always wired the same way. Pinout and voltage requirements vary by printer and drawer manufacturer. Using a standard phone cable without confirming compatibility can prevent the drawer from opening or damage the drawer interface. Check the printer manual, drawer documentation, and connector pin count before replacing this cable.
Some drawers use USB or serial interfaces, while others are manually opened or controlled by a dedicated POS interface. The correct method depends on the drawer and POS design, not simply the connector shape.
Display, Payment, and Legacy POS Connections
Not every connection at a POS station is for data alone. Displays and payment devices introduce additional cable requirements.
Video cables for POS and customer displays
Touchscreen terminals, rear displays, and customer-facing displays may use HDMI, DisplayPort, VGA, DVI, or USB-C video output. HDMI and DisplayPort are standard on newer equipment. VGA and DVI are more common on legacy terminals and monitors.
Before ordering an adapter, verify which direction the signal must travel. An HDMI-to-DisplayPort cable is not necessarily the same as a DisplayPort-to-HDMI cable. Active adapters may be required when connecting older and newer display standards. Also check screen resolution, mounting location, and cable length. A short, direct cable is preferable when the terminal and display are close together.
Payment terminal cables
Payment terminal connectivity depends on whether the device is countertop, mobile, or integrated with the POS. Countertop terminals commonly use Ethernet or Wi-Fi for network access and a dedicated power supply. Some use USB for integration, charging, or configuration. Older models may use serial connections.
Payment hardware should be installed according to the processor's requirements. The cable may fit physically while the device remains unsupported by the payment application or configured for a different communication method. For integrated payment setups, confirm the terminal model, POS platform, processor, and interface type before purchase.
Serial and USB-to-serial adapters
Many restaurants still operate reliable legacy devices, including pole displays, scales, printers, coin equipment, and older payment peripherals. These may require RS-232 serial cables. Newer POS terminals often lack a native serial port, making a quality USB-to-serial adapter necessary.
Not all adapters perform equally with POS hardware. Choose an adapter with supported drivers and a chipset suited to the operating system and application. A low-cost adapter that repeatedly changes COM port assignments can create recurring printer or display failures after a reboot.
Choosing the Right POS Cable Before You Order
Cable selection should begin with the equipment model and port labels, not a general description such as “printer cable” or “drawer cord.” Record the manufacturer and model of each device, inspect the connector at both ends, and identify whether the connection carries data, power, video, network traffic, or a drawer-open signal.
For an organized replacement order, verify these points:
- Connector type at both ends, such as USB-A to USB-B or RJ45 to RJ45.
- Required cable length, including routing through counter openings, conduit, or wall paths.
- Whether the cable needs to carry power, data, video, or Power over Ethernet.
- Device-specific requirements such as cash drawer pinout, serial wiring, or adapter voltage.
- Environmental needs, including strain relief, right-angle connectors, and secure cable management.
Label both ends of every installed cable, particularly in multi-station restaurants. A labeled Ethernet cable, printer lead, or power supply saves time when replacing equipment during a busy shift. It also reduces the chance that staff disconnect the wrong device while troubleshooting.
PCPOS Systems supports restaurant operators and technical buyers with POS hardware, network components, adapters, power supplies, and connection accessories that fit the equipment around the counter, kitchen, drive-thru, and back office. When a cable is uncertain, matching it to the exact device model is faster and safer than relying on appearance alone.
The right cable is a small part of the installation, but it carries the connection that keeps orders printing, payments moving, drawers opening, and service on pace. Keep critical spares on site, document each connection, and replace questionable cables before they become a shift-time failure.
